MO Series
|
| MO Series Flame-Proof
Type Metal Oxide Film Resistors |
| METAL
OXIDE FILM RESISTORS MO Series (Flame-Proof Type) |
1/4W, 1/2W, 1W, 2W, 3W, 5W
MO-25, MO-50, MO-100, MO-200, MO-300, MO-500 |
|
INTRODUCTION |
| These Metal Oxide
Resistors offer excellent performance in applications where
stability and uniformity of characteristics are desired. They
provide lower cost alternatives to Carbon Composition Resistors
and General Purpose Metal Films. Metal Oxide also can replace
many low power General Purpose Wire wound applications, saving
both money and time, with shorter delivery cycles. |
|
 |
|
FEATURES |
- High power-to-size ratio for
significant space savings.
- Excellent long-term stability.
- Complete flameproof construction.
- High surge/overload capability.
- Wide resistance range : 1 Ω ~ 1MΩ
- Standard tolerance : ?% , ?%
|
|
DIMENSIONS:
|
|
STYLE |
DIMENSION (mm) |
POWER RATING
(Watt) |
VALUE
RANGE |
|
L |
ФD
|
H |
Фd |
|
MO-25 |
6.3
?.5 |
2.3
?.3 |
28
? |
0.6
?.05 |
1/4W |
1Ω~1MΩ |
|
MO-50 |
9.5 ?.5 |
3.2 ?.3 |
26 ? |
0.6 ?.05 |
1/2W |
1Ω~1MΩ |
|
MO-100 |
11.5 ?.0 |
4.5
?.5 |
35
? |
0.8
?.05 |
1W
|
1Ω~1MΩ |
|
MO-200 |
15.5 ?.0 |
5.0 ?.5 |
33 ? |
0.8 ?.05 |
2W |
1Ω~1MΩ |
|
MO-300 |
17.5 ?.0 |
6.5
?.0 |
32
? |
0.8
?.05 |
3W
|
1Ω~1MΩ |
|
MO-500 |
24.5 ?.0 |
8.5 ?.0 |
38 ? |
0.8 ?.05 |
5W |
1Ω~1MΩ |
|
|
ELECTRICAL CHARACTERISTICS |
|
Style |
MO-25 |
MO-50 |
MO-100
|
MO-200
|
MF-300
|
MO-500
|
| Power Rating 70°C |
1/4W |
1/2W |
1W |
2W |
3W |
5W |
| Operating
Temp. Range |
-55°C
→
+155°C |
| Max. Working Voltage |
200V |
250V |
350V |
350V |
500V |
750V |
| Max.
Overload Voltage |
300V |
400V |
600V |
600V |
800V |
1000V |
| Dielectric Withstanding
Voltage (AC) |
350V |
350V |
500V |
500V |
700V |
800V |
| Max.
Intermittence Overload Voltage |
400V |
700V |
1000V |
1000V |
1000V |
1000V |
| Value Range ?%, ?%
|
1Ω ~510KΩ |
| Temp.
Coefficient (by Type) |
?00ppm/°C |
|
| * The
listed resistance range for standard resistance, below or over this
resistance is on request. |
|
ENVIRONMENTAL CHARACTERISTICS
|
|
PERFORMANCE TEST |
TEST METHOD |
APPRAISE |
|
Short Time Overload |
JIS-C-5202 5.5 : 2.5 times RCWV for 5 seconds |
?1%+0.05 Ω) |
|
Dielectric Withstanding V. |
JIS-C-5202 5.7 : in V-Block for 60
seconds |
By Type |
|
Temperature Coefficient |
JIS-C-5202 5.2 : -55°C ~+155°C |
MAX.
300ppm/°C |
|
Insulation Resistance |
JIS-C-5202 5.6 : in V-Block |
?1000 MΩ |
|
Solderability |
JIS-C-5202 6.5 : 230°C for 5 ?.5 seconds |
95%
min. coverage |
|
Resistance to Solvent |
JIS-C-5202 6.9 : Trichroethance
for 1 min. with ultrasonic |
no deterioration |
|
Terminal Strength |
Direct load for 10 sec. In the direction of the terminal leads
|
≥2.5KG/24.5N |
|
Pulse Overload |
JIS-C-5202 5.8 : 4 times RCWV 10000
cycles(1 sec.on, 25 sec.off) |
?2%+0.05 Ω) |
| Load
Life in Humidity |
JIS-C-5202 7.9 : 40 ?°C , 90~95% RH at RCWV for 1000 hrs
(1.5hrs. on, 0.5 hrs. off) |
?5%+0.05 Ω) |
|
Load Life |
JIS-C-5202 7.10 : 70°C at RCWV for
1000hrs (1.5hrs.on, 0.5hrs.off) |
?5%+0.05 Ω) |
|
Temperature Cycling |
JIS-C-5202 7.10 : -55°C→ room temp.→155°C→ room temp for 5 cycle |
?1%+0.05 Ω) |
|
Soldering Heat |
JIS-C-5202 7.10 : 350 ?0°C for 3
?.5 seconds |
?1%+0.05 Ω) |
|
 |
|
