Wildex EMI PC
Beads provide a powerful means of EMI/RFI attenuation for
electronic equipment. Multiple single turn printed circuit beads
or multi-turn printed circuit beads are available in three sizes
in B material.
These beads are supplied with tinned copper jumper wires which
complete the desired winding configuration on the printed
circuit boards.
Feature
Jumper wires are
oxygen free, and high conductivity copper with 95/5 tin/lead
coating.
Compact and high performance.
Easy installation.
Applications
The PC Beads mainly used in the PC
board of personal computers, microcomputers and relative devices
to filter the EMI from the outside.
