NLC SERIES |
MOLDING TYPE
WIRE WOUND CHIP INDUCTOR (NLC Series) |
The characteristics of this series perform low Rdc and carry large current.
The size format is from 2520 (1008) ~ 5650 (2220).
Best for power supply applications such as PC, conveyable telephone, and others
|
|
 |
- Very strong solderability by flow soldering, soldering iron or wave soldering.
- Highly accurate dimensions, can be mounted automatically.
- Terminals are highly resistant to pull forces.
- Highly resistant to mechanical shocks and pressure.
- Highly reliable in environments of sudden temperature change and humidity. Super Q characteristics.
|
- Microtelevisions, liquid crystal televisions, video cameras, portable VCRs, car radios, car stereos, thin tape radios, television tuners, mobile telephones, radio and other electronic devices.
|
| Shapes and Dimensions (NL322522 Series) |
| Shapes and Dimensions (NL453232 Series) |
| Shapes and Dimensions (NL565050 Series) |
| Molding Type Wire Wound Chip Inductors /High Curren/ 'NLC Series |
| NLC 453232Series |
|
NLC Reliability Test |
|
| NLC 565050 Series |
|
NLC Packaging |
|
