MKT |
| METALLIZED POLYESTER FILM CAPACITOR
Type: MKT Interference Suppressors Class - X2 |
MKT CAPACITORS are constructed with metalized polyester film dielectric, copperply lead, encapsulated in plastic case with epoxy resin sealed. They provide lnterference Siuppression with safety approvals of UL file No. E 127320.
|
|
APPLICATIONS: |
THE TYPE-MKT CAPACITORS are ideal for using Line-By-Pass, Antenna coupling. Accross-the line and Spark killer circuits and available for EMI filter and switching power supply application.
|
| FEATURES: |
- Non-inductive construction
- Self-healing property.Flame-retardant plastic case and epoxy resin.
(complicance with UL 94V-01)
- High moisture-resistance.
- Good solderability.
|
| SPECIFICATION: |
- OPERATING TEMPERATURE: -40 o C ~ +85 o C.
- CAPACITANCE RANGE : 0.001 μF ~ 0.47 μF.
- CAPACITANCE TOLERANCE :
±5%(J), ±10%(K), ±20%(M).
- RATED VOLTAGE : 250VAC, 50~60Hz
- DISSIPATION FACTOR : 1.0% MAX.( 1KHz, 25 o C )
- INSULATION RESISTANCE :
C ≦ 0.33 μF, I.R. ≧ 15,000 M Ω
C ≧ 0.33 μF, I.R. ≦ 5,000 M Ω. μF
|
|
 |
Unit:mm
| CAPACITANCE |
250VAC |
CAPACITANCE |
250VAC |
| Part No. |
CAP( μF) |
W |
H |
T |
P |
d ψ |
Part No. |
CAP( μF) |
W |
H |
T |
P |
d ψ |
| MPEX102 |
0.001 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX223 |
0.022 |
13.0 |
12.0 |
6.0 |
10.0 |
0.6 |
| MPEX122 |
0.0012 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX273 |
0.027 |
13.0 |
12.0 |
6.0 |
10.0 |
0.6 |
| MPEX152 |
0.0015 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX333 |
0.033 |
18.0 |
11.0 |
5.0 |
15.0 |
0.8 |
| MPEX182 |
0.0018 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX393 |
0.039 |
18.0 |
11.0 |
5.0 |
15.0 |
0.8 |
| MPEX222 |
0.0022 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX473 |
0.047 |
18.0 |
11.0 |
5.0 |
15.0 |
0.8 |
| MPEX272 |
0.0027 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX683 |
0.068 |
18.0 |
13.5 |
7.5 |
15.0 |
0.8 |
| MPEX332 |
0.0033 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX104 |
0.1 |
18.0 |
13.5 |
7.5 |
15.0 |
0.8 |
| MPEX392 |
0.0039 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX124 |
0.12 |
26.5 |
15.0 |
6.0 |
22.5 |
0.8 |
| MPEX472 |
0.0047 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX154 |
0.15 |
26.5 |
16.5 |
7.0 |
22.5 |
0.8 |
| MPEX562 |
0.0056 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX184 |
0.18 |
26.5 |
16.5 |
7.0 |
22.5 |
0.8 |
| MPEX682 |
0.0068 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX224 |
0.22 |
26.5 |
16.5 |
7.0 |
22.5 |
0.8 |
| MPEX822 |
0.0082 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX274 |
0.27 |
26.5 |
17.0 |
8.5 |
22.5 |
0.8 |
| MPEX103 |
0.01 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX334 |
0.33 |
32.0 |
20.0 |
11.0 |
27.5 |
0.8 |
| MPEX123 |
0.012 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX394 |
0.39 |
32.0 |
20.0 |
11.0 |
27.5 |
0.8 |
| MPEX153 |
0.015 |
13.0 |
11.0 |
5.0 |
10.0 |
0.6 |
MPEX474 |
0.47 |
32.0 |
20.0 |
11.0 |
27.5 |
0.8 |
|
|
